TT ELECTRONICS / WELWYN - W24-2R2 JI - Through Hole Resistor, 2.2 ohm, W24, 14 W, ± 5%, Axial Leaded, 750 V
- Resistance: 2.2ohm
- Product Range: W24 Series
- Power Rating: 14W
- Resistance Tolerance: ± 5%
- Resistor Case Style: Axial Leaded
- Voltage Rating: 750V
- Resistor Element Material: Wirewound
- Temperature Coefficient: ± 75ppm/°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 8mm
- External Length / Height: 53.5mm
- Full Power Rating Temperature: 70°C
- Lead Diameter: 0.8mm
- Lead Length: 30mm
- No. of Pins: 2Pins
- Operating Temperature Max: 350°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +350°C
- Power Rating at 25°C: 14W
- Resistor Mounting: Through Hole
- Temperature Coeff. +: 75ppm/°C
- Temperature Coeff. -: 75ppm/°C
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating V DC: 750V
