VLMB41P2Q2-GS08 LED, PLCC2, Blue Vishay

VISHAYUGS :VLMB41P2Q2-GS08 Code de commande:1561008

Prix:
Prix ​​promotionnel€1,60

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 4 produits disponibles

Documents et téléchargements

description

VISHAY - VLMB41P2Q2-GS08 - LED, Blue, SMD, PLCC-2, 20 mA, 3.2 V, 476 nm

  • LED Colour: Blue
  • LED Mounting: SMD
  • LED Case Size: PLCC-2
  • Forward Current If: 20mA
  • Forward Voltage: 3.2V
  • Wavelength Typ: 476nm
  • Luminous Intensity: 112mcd
  • Viewing Angle: 60°
  • Lens Shape: Round
  • Product Range: -
  • Automotive Qualification Standard: AEC-Q100
  • MSL: MSL 2A - 4 weeks
  • SVHC: No SVHC (15-Jan-2019)
  • Angle of Half Sensitivity ±: 60°
  • Bulb Size: 2.4mm
  • Dominant Wavelength: 476nm
  • External Depth: 1.75mm
  • External Length / Height: 3.5mm
  • External Width: 2.8mm
  • Forward Current If Max: 20mA
  • Forward Voltage VF Max: 4.2V
  • LED / Lamp Size: 2.4mm
  • LED Type: Standard
  • Luminous Intensity Max: 112mcd
  • Luminous Intensity Min: 56mcd
  • No. of Pins: 2Pins
  • Operating Temperature Max: 100°C
  • Operating Temperature Min: -40°C
  • Operating Temperature Range: -40°C to +100°C
  • Voltage Vf Typ: 3.2V
