UPS1V471MPD Cap, 470µF, 35V, 20% NICHICON

NICHICONUGS :UPS1V471MPD Code de commande:8813000

Prix:
Prix ​​promotionnel€0,79

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (3051 unité)

Documents et téléchargements

description

NICHICON - UPS1V471MPD - Electrolytic Capacitor, Miniature, 470 µF, 35 V, ± 20%, Radial Leaded, 1000 hours @ 105°C, Polar

  • Capacitance: 470µF
  • Voltage Rating: 35V
  • Product Range: PS Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 10mm
  • Lead Spacing: 5mm
  • Height: 20mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 1000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 20mm
  • Impedance: 0.65ohm
  • Lead Diameter: 0.5mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +105°C
  • Operating life Time: 3000h
  • Ripple Current AC: 250mA
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 35V
