TT ELECTRONICS / WELWYN - ULR1-R005FT2 - SMD Current Sense Resistor, 0.005 ohm, ULR, 2512 [6432 Metric], 1 W, ± 1%, Metal Strip
- Resistance: 0.005ohm
- Product Range: ULR Series
- Resistor Case Style: 2512 [6432 Metric]
- Power Rating: 1W
- Resistance Tolerance: ± 1%
- Resistor Element Material: Metal Strip
- Temperature Coefficient: ± 100ppm/°C
- Automotive Qualification Standard: AEC-Q200
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 0.5mm
- External Length / Height: 6.35mm
- External Width: 3.18mm
- No. of Pins: 2Pins
- Operating Temperature Max: 170°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +170°C
- Resistor Mounting: Surface Mount Device
- Temperature Coeff. +: 100ppm/°C
- Temperature Coeff. -: 100ppm/°C
- Tolerance +: 1%
- Tolerance -: 1%
- Voltage Rating: 200V
- Voltage Rating V DC: 200V
