TMR 3-1222 Converter, DC/DC, 3W, +/-12V/0.13a TRACO Power

TRACO POWERUGS :TMR 3-1222 Code de commande:1284238

Prix:
Prix ​​promotionnel€33,46

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (10 unité)

Documents et téléchargements

description

TRACO POWER - TMR 3-1222 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 3 W, 2 Output, 12 V, 125 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 3W
  • Output Voltage - Output 1: 12V
  • Output Current - Output 1: 125mA
  • Output Voltage - Output 2: -12V
  • Output Current - Output 2: 125mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TMR 3 Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 18V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: SIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 9.2mm
  • Height: 11.1mm
  • Depth: 21.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 81%
  • Isolation Voltage: 1.5kV
  • Load Regulation: 1%
  • No. of Outputs: 2Outputs
  • Output Current - Max: -125mA
  • Output Voltage +: +12VDC
  • Output Voltage -: -12VDC
  • Power Rating: 3W
  • Supply Voltage: 12V

Frais de port prévus
