TMR 1-1222 DC-DC Conv, ISO POL, 2 O/P, 0.042A, 12V TRACO Power

TRACO POWERUGS :TMR 1-1222 Code de commande:2414173

Prix:
Prix ​​promotionnel€16,59

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (5 unité)

Documents et téléchargements

description

TRACO POWER - TMR 1-1222 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 1 W, 2 Output, 12 V, 42 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 1W
  • Output Voltage - Output 1: 12V
  • Output Current - Output 1: 42mA
  • Output Voltage - Output 2: -12V
  • Output Current - Output 2: 42mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TMR 1 & TMR 1SM Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 18V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: SIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 7.62mm
  • Height: 11mm
  • Depth: 17mm
  • SVHC: No SVHC (27-Jun-2018)
  • No. of Outputs: 2Outputs
