HIROSE(HRS) - TM11APA-88P(03) - Modular Connector, RJ45 Plug, 1 x 1 (Port), 8P8C, Cat3, Cable Mount
- Modular Connector Type: RJ45 Plug
- Port Configuration: 1 x 1 Port
- No. of Positions / Loaded Contacts (per Port): 8P8C
- LAN Category: Cat3
- IP Rating: -
- Connector Mounting: Cable Mount
- Connector Orientation: Vertical
- Shielding: Unshielded
- Magnetics: Without Magnetics
- LEDs: Without LED
- Light Pipes: Without Light Pipe
- Product Range: TM11P Series
- Connector Type: RJ45
- Contact Material: Phosphor Bronze
- Contact Plating: Gold Plated Contacts
- Contact Termination: IDC / IDT
- Contact Termination Type: IDC / IDT
- Current Rating: 0.5A
- Gender: Plug
- Insulation Resistance: 100Mohm
- No. of Contacts: 8Contacts
- No. of Mating Cycles: 200
- No. of Ports: 1Ports
- No. of Positions: 8Ways
- Operating Temperature Max: 60°C
- Operating Temperature Min: -20°C
- Voltage Rating VAC: 125V
- Withstand Voltage: 500V
