CGS - TE CONNECTIVITY - TL2BR09F - SMD Current Sense Resistor, 0.09 ohm, TL, 1206 [3216 Metric], 250 mW, ± 1%, Metal Film
- Resistance: 0.09ohm
- Product Range: TL Series
- Resistor Case Style: 1206 [3216 Metric]
- Power Rating: 250mW
- Resistance Tolerance: ± 1%
- Resistor Element Material: Metal Film
- Temperature Coefficient: ± 75ppm/°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- External Length / Height: 0.6mm
- Full Power Rating Temperature: 70°C
- No. of Pins: 2Pins
- Operating Temperature Max: 170°C
- Operating Temperature Min: -65°C
- Operating Temperature Range: -65°C to +170°C
- Resistor Mounting: Surface Mount Device
- Temperature Coeff. +: 75ppm/°C
- Temperature Coeff. -: 75ppm/°C
- Tolerance +: 1%
- Tolerance -: 1%
