Ten 25-1211 Converter, DC/DC, 25W, 5V TRACO Power

TRACO POWERUGS :TEN 25-1211 Code de commande:1204988

Prix:
Prix ​​promotionnel€96,76

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 4 produits disponibles

Documents et téléchargements

description

TRACO POWER - TEN 25-1211 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 25 W, 1 Output, 5 V, 5 A

  • No. of Outputs: 1 Output
  • Output Power Max: 25W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 5A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEN 25 Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 18V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 40.6mm
  • Height: 9.5mm
  • Depth: 50.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CSA, cUL, EN, IEC, UL
  • Approvals & Standards: CSA, IEC, UL
  • Efficiency Max: 84%
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 1Outputs
  • Operating Temperature Max: +85°C
  • Operating Temperature Min: -40°C
  • Power Rating: 25W
  • Supply Voltage: 12V
