Tel 15-1223 Converter, DC/DC, 15w, +/-15V/0.5A TRACO Power

TRACO POWERUGS :TEL 15-1223 Code de commande:1242685

Prix:
Prix ​​promotionnel€69,73

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (11 unité)

Documents et téléchargements

description

TRACO POWER - TEL 15-1223 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 15 W, 2 Output, 15 V, 500 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 15W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 500mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 500mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TEL 15 Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 18V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 25.4mm
  • Height: 10.2mm
  • Depth: 50.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CSA, EN, IEC, UL
  • Approvals & Standards: CSA, IEC, UL
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 2Outputs
  • Output Voltage +: 15VDC
  • Output Voltage -: -15VDC
  • Power Rating: 15W
  • Supply Voltage: 12V

Frais de port prévus
