T92P11D24-24 Relay, DPDT, 277VAC, 30A Te Connectivity

TE CONNECTIVITYUGS :3-1423008-6 Code de commande:1629079

Prix:
Prix ​​promotionnel€27,54

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (76 unité)

Documents et téléchargements

description

TE CONNECTIVITY - 3-1423008-6 - General Purpose Relay, T92 Series, Power, Non Latching, DPDT, 24 VDC, 30 A

  • Contact Configuration: DPDT
  • Coil Voltage: 24VDC
  • Contact Current: 30A
  • Product Range: T92 Series
  • Relay Mounting: Panel
  • Coil Type: Non Latching
  • Contact Voltage VAC: 277VAC
  • Relay Terminals: Quick Connect
  • Contact Voltage VDC: -
  • Contact Material: Silver Cadmium Oxide
  • Coil Resistance: 350ohm
  • SVHC: No SVHC (27-Jun-2018)
  • AC Coil Power: 4VA
  • Approval Bodies: CSA, VDE
  • Approval Category: UL Recognised
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 20A
  • Contact Current Max: 30A
  • Contact Voltage AC Max: 277V
  • Contact Voltage AC Nom: 480V
  • Dielectric Voltage Coil to Contact: 4000V
  • Dielectric Voltage Contact to Contact: 1500V
  • External Depth: 34.54mm
  • External Height: 37.97mm
  • External Length / Height: 37.97mm
  • External Width: 52.07mm
  • Insulation Resistance: 1000Mohm
  • Nom Operating Power: 1.7W
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power
  • Type: Dust protected
