SRZ-1CT-DL-24Vdc Relay, Automotive, SPDT, 27VDC, 30A IMO Precision Controls

IMO PRECISION CONTROLSUGS :SRZ-1CT-DL-24VDC Code de commande:1094088

Prix:
Prix ​​promotionnel€10,51

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (843 unité)

Documents et téléchargements

description

IMO PRECISION CONTROLS - SRZ-1CT-DL-24VDC - Automotive Relay, 24 VDC, 30 A, SPDT, Through Hole, Solder, SRZ

  • Coil Voltage: 24VDC
  • Contact Current: 30A
  • Contact Configuration: SPDT
  • Relay Mounting: Through Hole
  • Relay Terminals: Solder
  • Product Range: SRZ Series
  • Contact Voltage DC Nom: 27V
  • Coil Resistance: 360ohm
  • Contact Material: Silver Tin Oxide
  • SVHC: No SVHC (07-Jul-2017)
  • Coil Voltage VDC Nom: 24V
  • Contact Current DC Max: 30A
  • Contact Current Max: 35A
  • Contact Voltage DC Max: 27V
  • DC Coil Power: 1.2W
  • External Depth: 23mm
  • External Height: 25.4mm
  • External Length / Height: 25.4mm
  • External Width: 15.5mm
  • Insulation Resistance: 100Mohm
  • Mechanical Life: 10,000,000 Operations
  • No. of Mechanical Operations: 10000000
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -40°C
  • Switch Current Max: 30A
  • Switching Current Max: 30A
  • Switching Power Max: 540W
