BOURNS - SRU1048-221Y - Power Inductor (SMD), 220 µH, 800 mA, Shielded, 700 mA, 10mm x 10mm x 4.8mm
- Inductance: 220µH
- RMS Current (Irms): 800mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 700mA
- Product Range: -
- Power Inductor Case: 10mm x 10mm x 4.8mm
- DC Resistance Max: 0.35ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 4.8mm
- External Length / Height: 10mm
- External Width: 10mm
- Inductor Type: Shielded Power Choke
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 20
- Q Test Frequency: 796kHz
- Resonant Frequency: 4MHz
- Self Resonant Frequency Min: 4MHz
- Test Frequency: 0.796MHz
