description
BOURNS - SRU1028-330Y - Power Inductor (SMD), 33 µH, 1.25 A, Shielded, 1.2 A, SRU1028, 10mm x 10mm x 2.8mm
- Inductance: 33µH
- RMS Current (Irms): 1.25A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.2A
- Product Range: SRU1028 Series
- Power Inductor Case: 10mm x 10mm x 2.8mm
- DC Resistance Max: 0.139ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (27-Jun-2018)
- External Depth: 2.8mm
- External Length / Height: 10mm
- External Width: 10mm
- Inductor Type: Shielded Power Choke
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 24
- Q Test Frequency: 2.52MHz
- Resonant Frequency: 12MHz
- Self Resonant Frequency Min: 12MHz
- Test Frequency: 2.52MHz
