BOURNS - SRR1206-331KL - Power Inductor (SMD), 330 µH, 600 mA, Shielded, 12.7mm x 12.7mm x 6.5mm
- Inductance: 330µH
- RMS Current (Irms): 600mA
- Inductor Construction: Shielded
- Saturation Current (Isat): -
- Product Range: -
- Power Inductor Case: 12.7mm x 12.7mm x 6.5mm
- DC Resistance Max: 0.66ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 6.5mm
- External Length / Height: 12.7mm
- External Width: 12.7mm
- Inductor Type: Shielded Power Choke
- Operating Temperature Max: 125°C
- Operating Temperature Min: 40°C
- Q Factor: 11
- Q Test Frequency: 796kHz
- Resonant Frequency: 3MHz
- Self Resonant Frequency Min: 3MHz
- Test Frequency: 0.796MHz
