SP-33 Transformer, Audio 0.05W Output Type Triad MAGNETICS

TRIAD MAGNETICSUGS :SP-33 Code de commande:1824898

Prix:
Prix ​​promotionnel€28,64

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

TRIAD MAGNETICS - SP-33 - Audio Transformer, 4.4:1, 1 kohm, 50 ohm, 50 mW, 100 kHz, 1 kV

  • Current Rating: 3mA
  • Primary Impedance: 1kohm
  • Secondary Impedance: 50ohm
  • Transformer Mounting: Through Hole
  • Product Range: Red Spec Series
  • External Depth: 7.9mm
  • External Length / Height: 11.8mm
  • External Width: 10.4mm
  • Power Rating: 50mW
  • Transformer Type: Audio
  • Turns Ratio: 4.4
