SEMIKRON - SKT760/16E - Thyristor Module, 696 A, 1600 V
- SCR Module Type: Single SCR
- Peak Repetitive Off-State Voltage, Vdrm: 1.6kV
- Gate Trigger Current Max, Igt: 200mA
- Current It av: 696A
- On State RMS Current IT(rms): 1.6kA
- Peak Non Rep Surge Current Itsm 50Hz: 15kA
- Holding Current Max Ih: 500mA
- Gate Trigger Voltage Max Vgt: 3V
- Operating Temperature Max: 125°C
- Product Range: -
- SVHC: No SVHC (15-Jun-2015)
- Case Temperature Tc: 80°C
- Current Itsm: 15000A
- External Depth: 26mm
- External Diameter: 58mm
- No. of Pins: 3Pins
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +125°C
- Repetitive Reverse Voltage Vrrm Max: 1600V
- Temperature Vgt: 25°C
- Termination Type: Quick Connect
- Thyristor Case: Module
- Thyristor Case Style: Module
- Thyristor Type: Thyristor
- Weight: 240g
