BOURNS - SDR7045-3R3M - Power Inductor (SMD), 3.3 µH, 2.8 A, Unshielded, 3.7 A, SDR7045, 7mm x 7mm x 4.5mm
- Inductance: 3.3µH
- RMS Current (Irms): 2.8A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 3.7A
- Product Range: SDR7045 Series
- Power Inductor Case: 7mm x 7mm x 4.5mm
- DC Resistance Max: 0.036ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 23
- Q Test Frequency: 7.96MHz
- Self Resonant Frequency Min: 47MHz
