description
BOURNS - SDR7045-2R2M - Power Inductor (SMD), 2.2 µH, 3.3 A, Unshielded, 4 A, SDR7045
- Inductance: 2.2µH
- RMS Current (Irms): 3.3A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 4A
- Product Range: SDR7045 Series
- Power Inductor Case: 7mm x 7mm x 4.5mm
- DC Resistance Max: 0.032ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 24
- Q Test Frequency: 7.96MHz
- Self Resonant Frequency Min: 79MHz
