description
- Inductance: 220µH
- RMS Current (Irms): 500mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 480mA
- Product Range: SDR7045 Series
- Power Inductor Case: 7mm x 7mm x 4.5mm
- DC Resistance Max: 0.93ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 22
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 6MHz
