description
BOURNS - SDR7045-150M - Power Inductor (SMD), 15 µH, 1.6 A, Unshielded, 1.9 A, SDR7045
- Inductance: 15µH
- RMS Current (Irms): 1.6A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 1.9A
- Product Range: SDR7045 Series
- Power Inductor Case: 7mm x 7mm x 4.5mm
- DC Resistance Max: 0.086ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 24
- Q Test Frequency: 2.52MHz
- Self Resonant Frequency Min: 19MHz
