BOURNS - SDR6603-331M - Power Inductor (SMD), 330 µH, 160 mA, Unshielded, 180 mA, SDR6603
- Inductance: 330µH
- RMS Current (Irms): 160mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 180mA
- Product Range: SDR6603 Series
- Power Inductor Case: 6.6mm x 4.45mm x 2.92mm
- DC Resistance Max: 3.8ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 42
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 5MHz
