BOURNS - SDR1006-6R8ML - Power Inductor (SMD), 6.8 µH, 3.4 A, Unshielded, 5.9 A, SDR1006, 9.8mm x 9.8mm x 5.8mm
- Inductance: 6.8µH
- RMS Current (Irms): 3.4A
- Inductor Construction: Unshielded
- Saturation Current (Isat): 5.9A
- Product Range: SDR1006 Series
- Power Inductor Case: 9.8mm x 9.8mm x 5.8mm
- DC Resistance Max: 0.044ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 9.8mm
- External Length / Height: 5.8mm
- External Width: 9.8mm
- No. of Pins: 2Pins
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Q Factor: 33
- Q Test Frequency: 7.96MHz
- Resonant Frequency: 32MHz
- Self Resonant Frequency Min: 32MHz
- Test Frequency: 7.96MHz
