MEAN WELL - SD-15B-12 - Isolated Chassis Mount DC/DC Converter, 2:1 Input, ITE, 2:1, 15 W, 1 Output, 12 V, 1.25 A
- No. of Outputs: 1 Output
- Output Power Max: 15W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 1.25A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Mounting: Panel
- DC / DC Converter Output Type: Fixed
- SVHC: No SVHC (12-Jan-2017)
- Approval Bodies: CE
- Approvals & Standards: CE
- DC / DC Converter Type: Enclosed
- Efficiency: 76%
- External Depth: 28mm
- External Length / Height: 79mm
- External Width: 51mm
- Input Voltage Max: 36V
- Input Voltage Min: 18V
- Isolation Voltage: 3kV
- Line Regulation: 0.3%
- Load Regulation: 0.3%
- No. of Outputs: 1Outputs
- Operating Temperature Max: 60°C
- Operating Temperature Min: -10°C
- Output Current: 1.25A
- Output Current Max: 1.25A
- Output Ripple Voltage pk-pk: 120mV
- Output Voltage: 12V
- Output Voltage Nom.: 12V
- Power Rating: 15W
- Supply Voltage: 36V
