SCHRACK - TE CONNECTIVITY - 1415899-4 - General Purpose Relay, RZ Series, Power, Non Latching, SPST-NO, 12 VDC, 12 A
- Contact Configuration: SPST-NO
- Coil Voltage: 12VDC
- Contact Current: 12A
- Product Range: RZ Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 360ohm
- SVHC: No SVHC (27-Jun-2018)
- Coil Voltage VDC Nom: 12V
- Contact Current Max: 12A
- Contact Voltage AC Nom: 250V
- External Depth: 29mm
- External Height: 15.7mm
- External Width: 12.7mm
- Nom Operating Power: 400mW
- Relay Type: Power
