TE CONNECTIVITY - 1649328-4 - General Purpose Relay, Power PCB Relay RT1 Series, Power, Non Latching, SPDT, 12 VDC, 16 A
- Contact Configuration: SPDT
- Coil Voltage: 12VDC
- Contact Current: 16A
- Product Range: RT1 Series
- Relay Mounting: Through Hole
- Coil Type: DC
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 360ohm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: BEAB, CSA, KEMA-KEUR, SEMKO, SETI, VDE
- Approval Category: UL Recognised
- Approvals & Standards: CSA, UL, VDE
- Coil Current: 33.3mA
- Coil Operating Lower Percent Limit: 70%
- Coil Operating Upper Percent Limit: 175%
- Coil Voltage VDC Nom: 12V
- Contact Current AC Max: 16A
- Contact Current DC Max: 20A
- Contact Current Max: 16A
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 277V
- Contact Voltage DC Max: 30V
- Contact Voltage DC Nom: 30V
- DC Coil Power: 400mW
- Dielectric Voltage Coil to Contact: 5kV
- Dielectric Voltage Contact to Contact: 1kV
- External Depth: 15.7mm
- External Height: 29mm
- External Length / Height: 29mm
- External Width: 12.7mm
- Lead Spacing: 5mm
- Relay Type: Power
