RFH54015WG Relay, SPST-NC, 250VAC, 16A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYUGS :RFH54015WG Code de commande:1891919

Prix:
Prix ​​promotionnel€13,72

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (135 unité)

Documents et téléchargements

description

SCHRACK - TE CONNECTIVITY - 2-1833005-3 - General Purpose Relay, RF Series, Power, Non Latching, SPST-NC, 15 VDC, 16 A

  • Contact Configuration: SPST-NC
  • Coil Voltage: 15VDC
  • Contact Current: 16A
  • Product Range: RF Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 565ohm
  • Coil Voltage VDC Nom: 15V
  • Contact Current Max: 16A
  • Contact Voltage AC Nom: 250V
  • External Depth: 29mm
  • External Height: 16mm
  • External Width: 13.2mm
  • Nom Operating Power: 400mW
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power
