description
BULGIN LIMITED - PX0822/S - Circular Connector, Buccaneer Standard Series, Panel Mount Receptacle, 25 Contacts
- Product Range: Buccaneer Standard Series
- Circular Connector Shell Style: Panel Mount Receptacle
- No. of Contacts: 25Contacts
- Circular Contact Type: -
- Coupling Style: -
- Connector Body Material: Nylon (Polyamide), Glass Filled Body
- Connector Body Plating: -
- Contact Material: -
- Contact Plating: -
- SVHC: No SVHC (27-Jun-2018)
- Cable Diameter Max: 9mm
- Colour: Black
- Connector Mounting: Panel Mount
- Connector Type: Circular Industrial
- Contact Gender: Socket
- Contact Resistance Max: 5mohm
- Current Rating: 1A
- External Diameter: 38.1mm
- External Length / Height: 28mm
- Flammability Rating: UL94V-0
- Gender: Receptacle
- IP / NEMA Rating: IP68
- Insulation Resistance: 100Mohm
- No. of Positions: 25Ways
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Voltage Rating V DC: 50V
- Voltage Rating VAC: 50V
- Working Voltage: 50V
