BLOCK - PT 4.5/2/12 - PCB Transformer, EI 42 x 14.8, Encapsulated Safety Isolating, 230V, 2 x 12V, 4.5 VA, 50Hz / 60Hz
- Power Rating: 4.5VA
- Secondary Voltages: 2 x 12V
- Current Rating: 186mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: PT Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 4.5VA
- External Depth: 33mm
- External Length / Height: 44mm
- External Width: 37mm
- Hole Spacing - Length: 25mm
- Input Voltage: 230V
- Lead Spacing: 5mm
- Output 2 Voltage Max: 12V
- Output Voltage: 12V
- Pin Diameter: 0.8mm
- Pin Length: 7mm
- Pitch Spacing: 25mm
- Primary Voltages: 1 x 230V
- Secondary Power: 2.25VA
- Single Primary Voltage: 230
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Test Voltage: 5kV
- Transformer Type: Encapsulated
- Weight: 190g
