PT 13/2/12 Transformer, 13VA, 2 X 12V Block

BLOCKUGS :PT 13/2/12 Code de commande:1711429

Prix:
Prix ​​promotionnel€43,47

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (6 unité)

Documents et téléchargements

description

BLOCK - PT 13/2/12 - PCB Transformer, EI 54 x 18.8, Encapsulated Safety Isolating, 230V, 2 x 12V, 13 VA, 50Hz / 60Hz

  • Power Rating: 13VA
  • Secondary Voltages: 2 x 12V
  • Current Rating: 542mA
  • Isolation Transformer Primary Voltages: 1 x 230V
  • Plug Type: -
  • Product Range: PT Series
  • SVHC: No SVHC (12-Jan-2017)
  • AC Power: 13VA
  • External Depth: 40mm
  • External Length / Height: 56mm
  • External Width: 47mm
  • Hole Spacing - Length: 30mm
  • Input Voltage: 230V
  • Lead Spacing: 5mm
  • Output 2 Voltage Max: 12V
  • Output Voltage: 12V
  • Pin Diameter: 0.8mm
  • Pin Length: 7mm
  • Pitch Spacing: 30mm
  • Primary Voltages: 1 x 230V
  • Secondary Power: 6.5VA
  • Single Primary Voltage: 230
  • Supply Frequency Max: 60Hz
  • Supply Frequency Min: 50Hz
  • Test Voltage: 5kV
  • Transformer Type: Encapsulated
  • Weight: 420g
