MICROCHIP - PIC16F1513-E/SS - 8 Bit MCU, Flash, PIC16 Family PIC16F15xx Series Microcontrollers, 20 MHz, 7 KB, 256 Byte, 28 Pins
- Product Range: PIC16 Family PIC16F15xx Series Microcontrollers
- CPU Speed: 20MHz
- Program Memory Size: 7KB
- RAM Memory Size: 256Byte
- No. of Pins: 28Pins
- MCU Case Style: SSOP
- No. of I/O's: 25I/O's
- Embedded Interface Type: EUSART, I2C, SPI
- Supply Voltage Min: 2.3V
- Supply Voltage Max: 5.5V
- MCU Family: PIC16
- MCU Series: PIC16F15xx
- Automotive Qualification Standard: AEC-Q100
- RoHS Phthalates Compliant: Yes
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (27-Jun-2018)
- Controller Family/Series: PIC16F151x
- MPU Core Size: 8bit
- No. of PWM Channels: 2
- No. of Timers: 3
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +125°C
- Oscillator Type: External, Internal
- Peripherals: ADC
- Program Memory Size: 7KB
- Supply Voltage Range: 2.3V to 5.5V
