LCR COMPONENTS - PC/HV/S/WF 1NF 1KV - Power Film Capacitor, Metallized PP, Axial Leaded, 1000 pF, ± 20%, High Frequency, Through Hole
- Capacitance: 1000pF
- Voltage Rating: 1kV
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 20%
- Product Range: PC/HV/S/WF Series
- Capacitor Case Style: -
- Capacitor Terminals: Axial Leaded
- Lead Spacing: -
- Operating Temperature Min: -55°C
- Operating Temperature Max: 100°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 9mm
- Capacitance Tolerance ±: ± 20%
- Capacitor Mounting: Through Hole
- Climatic Category: 40/85/56
- External Length / Height: 20mm
- Height: 20mm
- Insulation Resistance: 100000Mohm
- Lead Length: 40mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +100°C
- Power Factor: 0.0005
- Power Factor Frequency: 1kHz
- Pulse Rating: 1000V/µs
- Temperature Coeff. -: -200ppm/°C
- Temperature Coefficient: -200ppm/°C
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 1kV
- Voltage Rating VAC: 350V
