N3429-6202RB HEADER, STRAIGHT, S/LATCH, 26WAY 3M

3MUGS :N3429-6202RB Code de commande:9838201

Prix:
Prix ​​promotionnel€8,63

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (237 unité)

Documents et téléchargements

description

3M - N3429-6202RB - Pin Header, Short Latch, Wire-to-Board, 2.54 mm, 2 Rows, 26 Contacts, Through Hole Straight, 3000

  • Pitch Spacing: 2.54mm
  • No. of Contacts: 26Contacts
  • Gender: Header
  • Product Range: 3000 Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 2Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Copper
  • SVHC: No SVHC (15-Jan-2018)
  • Colour: Black
  • Contact Resistance: 20mohm
  • Current Rating: 1A
  • Current Temperature: 70°C
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 1000Mohm
  • No. of Mating Cycles: 200
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -55°C
  • PCB Hole Diameter: 0.89mm
  • Voltage Rating VAC: 350V
  • Working Voltage: 350V
