MR061A103KTA Cap, 0.01µF, 100V, 10%, C0G/NP0 KYOCERA Avx

KYOCERA AVXUGS :MR061A103KTA Code de commande:570679

Prix:
Prix ​​promotionnel€12,24

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (443 unité)

Documents et téléchargements

description

KYOCERA AVX - MR061A103KTA - Multilayer Ceramic Capacitor, 10000 pF, 100 V, ± 10%, Radial Leaded, C0G / NP0, 5.08 mm

  • Capacitance: 10000pF
  • Voltage Rating: 100V
  • Product Range: Ceralam MR Series
  • Capacitance Tolerance: ± 10%
  • Capacitor Terminals: Radial Leaded
  • Dielectric Characteristic: C0G / NP0
  • Lead Spacing: 5.08mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 125°C
  • Automotive Qualification Standard: -
  • SVHC: Lead (15-Jan-2019)
  • Capacitance Tolerance ±: ± 10%
  • External Depth: 2.28mm
  • External Length / Height: 7.36mm
  • External Width: 7.36mm
  • Height: 7.36mm
  • Lead Diameter: 0.6mm
  • Lead Length: 30mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +125°C
  • Temperature Coefficient: 0ppm/°C ± 30ppm/°C
  • Tolerance +: 10%
  • Tolerance -: 10%
  • Voltage Rating V DC: 100V
