MR051A150JTA Cap, 15PF, 100V, 5%, C0G/NP0 KYOCERA Avx

KYOCERA AVXUGS :MR051A150JTA Code de commande:669647

Prix:
Prix ​​promotionnel€9,92

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (101 unité)

Documents et téléchargements

description

KYOCERA AVX - MR051A150JTA - Multilayer Ceramic Capacitor, 15 pF, 100 V, ± 5%, Radial Leaded, C0G / NP0, 5.08 mm

  • Capacitance: 15pF
  • Voltage Rating: 100V
  • Product Range: Ceralam MR Series
  • Capacitance Tolerance: ± 5%
  • Capacitor Terminals: Radial Leaded
  • Dielectric Characteristic: C0G / NP0
  • Lead Spacing: 5.08mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 125°C
  • Automotive Qualification Standard: -
  • SVHC: Lead (15-Jan-2019)
  • Capacitance Tolerance ±: ± 5%
  • External Depth: 2.28mm
  • External Length / Height: 4.83mm
  • External Width: 4.83mm
  • Lead Diameter: 0.6mm
  • Lead Length: 30mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +125°C
  • Temperature Coefficient: 0ppm/°C ± 30ppm/°C
  • Tolerance +: 5%
  • Tolerance -: 5%
  • Voltage Rating V DC: 100V
