WIMA - MKS4C034703C00KSSD - General Purpose Film Capacitor, Metallized PET, Radial Box - 2 Pin, 0.47 µF, ± 10%, 40 V, 63 V
- Capacitance: 0.47µF
- Voltage Rating: 63V
- Capacitor Dielectric Type: PET (Polyester)
- Capacitance Tolerance: ± 10%
- Product Range: MKS4 Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 10mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 100°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 10%
- Capacitor Mounting: Through Hole
- Climatic Category: 55/100/56
- External Depth: 4mm
- External Length / Height: 9mm
- External Width: 13mm
- Height: 9mm
- Insulation Resistance: 4700Mohm
- Lead Diameter: 0.7mm
- Lead Length: 6mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +100°C
- Power Factor: 0.008
- Temperature Coeff. +: 300ppm/°C
- Temperature Coeff. -: -300ppm/°C
- Temperature Coefficient: ± 300ppm/°C
- Tolerance +: 10%
- Tolerance -: 10%
- Voltage Rating V DC: 63V
- Voltage Rating VAC: 40V
