MCCB1A107M2ECB Cap, 100µF, 10V, 20% multicomp Pro

MULTICOMP PROUGS :MCCB1A107M2ECB Code de commande:9708308

Prix:
Prix ​​promotionnel€5,28

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1055 unité)

Documents et téléchargements

description

MULTICOMP PRO - MCCB1A107M2ECB - Tantalum Capacitor, 100 µF, 10 V, ± 20%, PC Pin, 5.1 mm, 1 ohm

  • Capacitance: 100µF
  • Voltage Rating: 10V
  • Product Range: MCCB Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Lead Spacing: 5.1mm
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 125°C
  • ESR: 1ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Body Diameter: 9mm
  • Capacitance Tolerance ±: ± 20%
  • External Depth: 8.5mm
  • External Length / Height: 13mm
  • External Width: 8.5mm
  • Height: 13mm
  • Impedance: 1ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.5mm
  • Leakage Current: 8µA
  • No. of Pins: 2Pins
  • Operating Temperature Range: -55°C to +125°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 10V
