MC0125W12061330K Res, 330K, 1%, 0.125W, 1206, Thick Film multicomp

MULTICOMPUGS :MC0125W12061330K Code de commande:9336389

Prix:
Prix ​​promotionnel€0,05

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (3220 unité)

Documents et téléchargements

description

MULTICOMP - MC0125W12061330K - SMD Chip Resistor, 330 kohm, ± 1%, 125 mW, 1206 [3216 Metric], Thick Film, General Purpose

  • Resistor Case Style: 1206 [3216 Metric]
  • Resistance: 330kohm
  • Product Range: MC 1% Series
  • Voltage Rating: 200V
  • Resistor Element Material: Thick Film
  • Power Rating: 125mW
  • Resistance Tolerance: ± 1%
  • Temperature Coefficient: ± 100ppm/°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • External Depth: 0.65mm
  • External Length / Height: 3.2mm
  • External Width: 1.6mm
  • No. of Pins: 2Pins
  • Operating Temperature Max: 155°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +155°C
  • Reel Quantity: 5000
  • Resistor Mounting: Surface Mount Device
  • Tape Width: 8mm
  • Temperature Coeff. +: 100ppm/°C
  • Temperature Coeff. -: 100ppm/°C
  • Tolerance +: 1%
  • Tolerance -: 1%
  • Voltage Rating V DC: 200V
