MBRS4201T3G Diode, Schottky ONSEMI

ONSEMIUGS :MBRS4201T3G Code de commande:1611500

Prix:
Prix ​​promotionnel€2,00

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (8620 unité)

Documents et téléchargements

description

ONSEMI - MBRS4201T3G - Schottky Rectifier, 200 V, 4 A, Single, DO-214AB (SMC), 2 Pins, 860 mV

  • Repetitive Reverse Voltage Vrrm Max: 200V
  • Forward Current If(AV): 4A
  • Diode Configuration: Single
  • Diode Case Style: DO-214AB
  • No. of Pins: 2Pins
  • Forward Voltage VF Max: 860mV
  • Forward Surge Current Ifsm Max: 100A
  • Operating Temperature Max: 150°C
  • Product Range: MBRS4 Series
  • Automotive Qualification Standard: AEC-Q101
  • SVHC: Lead (27-Jun-2018)
  • Current Ifsm: 100A
  • Diode Type: Fast Recovery
  • Junction Temperature Tj Max: 150°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +150°C
  • Reverse Recovery Time trr Max: 35ns
  • Semiconductor Technology: Si
  • Termination Type: Surface Mount Device
