Documents et téléchargements
description
VISHAY - MAL210118333E3 - Electrolytic Capacitor, Screw, 33000 µF, 63 V, ± 20%, Screw, 10000 hours @ 85°C
- Capacitance: 33000µF
- Voltage Rating: 63V
- Product Range: 101 PHR-ST Series
- Lifetime @ Temperature: 10000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 50mm
- Lead Spacing: 22.2mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 105mm
- ESR: 0.014ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 12A
- AC Ripple Current @ 20kHz: 12A
- Capacitance Tolerance ±: ± 20%
- Capacitor Mounting: Panel
- Climatic Category: 40/085/86
- External Length / Height: 105mm
- Leakage Current: 4.16mA
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Operating life Time: 10000h
- Ripple Current AC: 12A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 85°C
- Tolerance +: 0.2%
- Tolerance -: 0.2%
- Voltage Rating DC Max: 63V
- Voltage Rating V DC: 63V
