VISHAY - MAL205857682E3 - Electrolytic Capacitor, Long Life, 6800 µF, 40 V, ± 20%, Quick Connect, Snap-In, 5000 hours @ 105°C
- Capacitance: 6800µF
- Voltage Rating: 40V
- Product Range: 058 PLL-SI Series
- Lifetime @ Temperature: 5000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 30mm
- Lead Spacing: 10mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Height: 40mm
- ESR: 0.042ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 3.94A
- Capacitance Tolerance ±: ± 20%
- Capacitor Mounting: Through Hole
- Climatic Category: 40/105/56
- ESR Frequency: 100Hz
- ESR Temperature: 20°C
- External Length / Height: 40mm
- Impedance: 29mohm
- Impedance Frequency: 10kHz
- Impedance Temperature: 20°C
- Leakage Current: 2574.4µA
- No. of Pins: 2Pins
- Operating Life Temperature: 40°C
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 5000h
- PCB Hole Diameter: 2mm
- Ripple Current AC: 3.94A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 105°C
- Tolerance +: 0.2%
- Tolerance -: 0.2%
- Voltage Rating DC Max: 40V
