VISHAY - MAL205849102E3 - Electrolytic Capacitor, Long Life, 1000 µF, 100 V, ± 20%, Quick Connect, Snap-In
- Capacitance: 1000µF
- Voltage Rating: 100V
- Product Range: 058 PLL-SI Series
- Lifetime @ Temperature: 10000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 25mm
- Lead Spacing: 10mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Height: 40mm
- ESR: 0.158ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- AC Ripple Current @ 100Hz: 1.85A
- Capacitance Tolerance ±: ± 20%
- Capacitor Mounting: Through Hole
- Climatic Category: 40/105/56
- ESR Frequency: 100Hz
- ESR Temperature: 20°C
- External Length / Height: 40mm
- Impedance: 115mohm
- Impedance Frequency: 10kHz
- Impedance Temperature: 20°C
- Leakage Current: 604µA
- No. of Pins: 2Pins
- Operating Life Temperature: 40°C
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 10000h
- PCB Hole Diameter: 2mm
- Ripple Current AC: 1.85A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 105°C
- Tolerance +: 0.2%
- Tolerance -: 0.2%
- Voltage Rating DC Max: 100V
