M63X103KB40 Trimmer, Pot, 10K, 1TURN, THD Vishay

VISHAY - M63X103KB40 - Trimpot, Single Turn, Cermet, Side Adjust, 10 kohm, Through Hole, 1 Turns

• Track Resistance: 10kohm
• No. of Turns: 1Turns
• Potentiometer Mounting: Through Hole
• Product Range: 63X Series
• Power Rating: 500mW
• Resistance Tolerance: ± 10%
• Temperature Coefficient: ± 100ppm/°C
• Automotive Qualification Standard: -
• MSL: -
• Adjustment Type: Screwdriver Slot
• Approval Category: MIL-R-22097
• Contact Resistance Variation +: 1%
• End Resistance: 2ohm
• External Length / Height: 10.03mm
• Full Power Rating Temperature: 70°C
• Lead Cross-section Depth: 0.81mm
• Lead Cross-section Width: 0.25mm
• Operating Temperature Max: 125°C
• Operating Temperature Min: -55°C
• Operating Temperature Range: -55°C to +125°C
• Proof Voltage: 1000V
• Resistance: 10kohm
• Resistor Element Material: Cermet
• Resistor Mounting: Through Hole
• Resistor Terminals: Radial Leaded
• Rotation Mechanical Angle: 270°
• Temperature Coeff. +: 100ppm/°C
• Temperature Coeff. -: 100ppm/°C
• Tolerance +: 10%
• Tolerance -: 10%
• Track Taper: Linear
• Voltage Rating: 400V
• Voltage Rating V DC: 300V
