KINGBRIGHT - KPTD-3216SGC - LED, Low Power, Green, SMD, 1206 (3216 Metric), 20 mA, 2.2 V, 568 nm
- LED Colour: Green
- LED Mounting: SMD
- LED Case Size: 1206 (3216 Metric)
- Forward Current If: 20mA
- Forward Voltage: 2.2V
- Wavelength Typ: 568nm
- Luminous Intensity: 20mcd
- Viewing Angle: 40°
- Lens Shape: Round
- Product Range: -
- Automotive Qualification Standard: -
- MSL: MSL 3 - 168 hours
- SVHC: No SVHC (15-Jan-2019)
- Dominant Wavelength: 568nm
- External Depth: 1.6mm
- External Length / Height: 1.8mm
- External Width: 3.2mm
- Forward Current If Max: 20mA
- Forward Voltage VF Max: 2.5V
- LED / Lamp Size: 1.6mm
- LED Type: Standard
- Luminous Intensity @ If Min: 5mcd
- Luminous Intensity Typ: 20mcd
- Material: GaP
- No. of Pins: 2Pins
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +85°C
- PIV Max: 5V
- Peak Wavelength: 565nm
- Reverse Leakage Current Max: 10µA
- Storage Temperature Max: 85°C
- Storage Temperature Min: -40°C
- Voltage Vf Typ: 2.2V
