JTL4024S12 DC/DC CONVERTER, 40W 2X2" SINGLE O/P XP POWER

XP POWERUGS :JTL4024S12 Code de commande:1821380

Prix:
Prix ​​promotionnel€137,09

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (39 unité)

Documents et téléchargements

description

XP POWER - JTL4024S12 - Isolated Through Hole DC/DC Converter, High Power Density, ITE, 4:1, 40 W, 1 Output, 12 V, 3.35 A

  • No. of Outputs: 1 Output
  • Output Power Max: 40W
  • Output Voltage - Output 1: 12V
  • Output Current - Output 1: 3.35A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: JTL40 Series
  • Input Voltage DC Min: 9V
  • Input Voltage DC Max: 36V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: DIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 50.8mm
  • Height: 10.2mm
  • Depth: 50.8mm
  • SVHC: No SVHC (15-Jan-2018)
  • Isolation Voltage: 1.6kV
  • No. of Outputs: 1Outputs
  • Power Rating: 40W
  • Supply Voltage: 24V
