XP POWER - JCA0348S05 - Isolated Through Hole DC/DC Converter, 2:1 Input, ITE, 2:1, 3 W, 1 Output, 5 V, 600 mA
- No. of Outputs: 1 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 600mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: JCA Series
- Input Voltage DC Min: 36V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.3mm
- Height: 10mm
- Depth: 25.4mm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CE, CSA, EN, LVD, UL
- Approvals & Standards: CE, CSA, UL
- Efficiency: 74%
- External Depth: 10mm
- External Length / Height: 25.4mm
- External Width: 20.3mm
- Isolation Voltage: 1.5kV
- No. of Outputs: 1Outputs
- Operating Temperature Max: 75°C
- Operating Temperature Min: -40°C
- Power Rating: 3W
- Supply Voltage: 48V
