IXFN180N15P MOSFET, N, Sot-227B IXYS Semiconductor

IXYS SEMICONDUCTORUGS :IXFN180N15P Code de commande:1427321

Prix:
Prix ​​promotionnel€34,80

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (929 unité)

Documents et téléchargements

description

IXYS SEMICONDUCTOR - IXFN180N15P - Power MOSFET, N Channel, 150 V, 150 A, 0.011 ohm, ISOTOP, Module

  • Transistor Polarity: N Channel
  • Continuous Drain Current Id: 150A
  • Drain Source Voltage Vds: 150V
  • On Resistance Rds(on): 0.011ohm
  • Rds(on) Test Voltage Vgs: 10V
  • Threshold Voltage Vgs: 5V
  • Power Dissipation Pd: 680W
  • Transistor Case Style: ISOTOP
  • No. of Pins: 4Pins
  • Operating Temperature Max: 175°C
  • Product Range: -
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (12-Jan-2017)
  • Capacitance Ciss Typ: 7000pF
  • Current Id Max: 150A
  • Junction to Case Thermal Resistance A: 0.22°C/W
  • N-channel Gate Charge: 240nC
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +175°C
  • Reverse Recovery Time trr Max: 200ns
  • Termination Type: Screw
  • Voltage Vds Typ: 150V
  • Voltage Vgs Max: 20V
  • Voltage Vgs Rds on Measurement: 10V
