XP POWER - IE1205D - Isolated Through Hole DC/DC Converter, 1kV Isolation, ITE, 1:1, 1 W, 1 Output, 5 V, 200 mA
- No. of Outputs: 1 Output
- Output Power Max: 1W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 200mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: IE Series
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 10.14mm
- Height: 6.86mm
- Depth: 12.7mm
- SVHC: No SVHC (15-Jan-2018)
- Efficiency Max: 80%
- Isolation Voltage: 1kV
- Line Regulation: 1.2%
- Load Regulation: 8%
- No. of Outputs: 1Outputs
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Output Voltage Min: 10.8V
- Power Rating: 1W
- Supply Voltage: 12V
