OMRON - G7L-2A-TUB-80-CB AC200/240 - General Purpose Relay, G7L Series, Power, Non Latching, DPST-NO, 240 VAC, 25 A
- Contact Configuration: DPST-NO
- Coil Voltage: 240VAC
- Contact Current: 25A
- Product Range: G7L Series
- Relay Mounting: Panel
- Coil Type: Non Latching
- Contact Voltage VAC: 277VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: -
- Contact Material: Silver Alloy
- Coil Resistance: 21kohm
- SVHC: No SVHC (17-Dec-2015)
- Approvals & Standards: CSA, IEC, UL
- Coil Current: 10.2mA
- Coil Voltage VAC Nom: 240V
- Contact Current AC Max: 25A
- Contact Current Max: 25A
- Contact Voltage AC Nom: 250V
- External Depth: 33.5mm
- External Height: 47mm
- External Length / Height: 47mm
- External Width: 68.5mm
- Nom Operating Power: 2.5VA
- Operating Temperature Max: 60°C
- Operating Temperature Min: -25°C
- Relay Type: Power - General Purpose
