OMRON - G7L-2A-T 200/240AC - Power Relay, DPST-NO, 240 VAC, 25 A, G7L, Panel Mount, Non Latching
- Contact Configuration: DPST-NO
- Coil Voltage: 240VAC
- Contact Current: 25A
- Product Range: G7L Series
- Relay Mounting: Panel
- Coil Type: Non Latching
- Contact Voltage VAC: 220VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: -
- Contact Material: Silver Alloy
- Coil Resistance: 21kohm
- SVHC: No SVHC (07-Jul-2017)
- AC Coil Power: 2.5VA
- Approvals & Standards: CSA, IEC, UL
- Coil Current: 10.2mA
- Coil Operating Lower Percent Limit: 75%
- Coil Operating Upper Percent Limit: 110%
- Coil Voltage Max: 240VAC
- Coil Voltage Min: 200VAC
- Coil Voltage VAC Nom: 240V
- Contact Current AC Max: 25A
- Contact Current Max: 25A
- Contact Voltage AC Max: 220V
- Contact Voltage AC Nom: 220V
- External Depth: 47mm
- External Height: 52.5mm
- External Length / Height: 52.5mm
- External Width: 33.5mm
- Nom Operating Power: 2.5VA
- Operating Temperature Max: 60°C
- Operating Temperature Min: -25°C
- Relay Type: Power - General Purpose
